MYIR | Single Board Computers

Z-turn Board

Now includes NABL Calibration Certificate.

The Z-turn Board is a high-performance Single Board Computer (SBC) based on Xilinx Zynq-7010/7020 SoC. It integrates a dual-core ARM Cortex-A9 processor and Xilinx 7-series FPGA logic, offering versatile connectivity options for industrial and embedded applications..

  • Detail
  • Special Features
  • Specification

  • Processor: Xilinx XC7Z010-1CLG400 (Zynq-7010) or XC7Z020-2CLG400 (Zynq-7020), ARM Cortex-A9 (667MHz to 866MHz) and ARM Cortex-R5 (600MHz), integrated FPGA.

  • Memory: 1GB DDR3 SDRAM, 16MB QSPI Flash, 32KB EEPROM.

  • Storage: 1 microSD slot, 1 x TF Card interface.

  • Display: HDMI (1080p), LVDS for external displays.

  • Connectivity: 1 x Gigabit Ethernet, 1 x USB 2.0 Host, 1 x Mini USB OTG, 1 x USB-UART debug port.

  • Expansion: 2 x 20-pin headers for I/O expansion, 1 x MIPI-CSI Camera interface.

  • Power Supply: 5V/2A (USB or external), low power consumption (~0.25A without peripherals).

  • Temperature: Operating range of 0°C to 70°C (commercial grade).

  • OS Support: Linux 4.14.0, Yocto, and Python development support.



  • Processor: Powered by Xilinx Zynq-7010/7020 with ARM Cortex-A9 and 28K–85K logic cells in FPGA for high customization.

  • Memory: 1GB DDR3, 16MB QSPI Flash, and microSD storage.

  • Connectivity: Includes USB, Ethernet, CAN, HDMI, and MIPI-CSI interfaces.

  • Advanced I/O: Offers expansion through 2 x 20-pin headers, configurable I/O with up to 39 LVDS pairs.

  • Sensors: Onboard three-axis acceleration and temperature sensors for real-time monitoring.

  • Power Efficiency: USB or 5V/2A power supply with low consumption.

  • Dimensions: 63mm x 102mm x 1.6mm, 8-layer PCB design.

  • Buttons: Reset and user buttons, 5 LEDs (status indicators).

  • RTC: Optional RTC support with battery holder.
